EMC VDMA Pneumatic Cylinders - 50mm Bore Cylinderscylinderemc

ALL OUR FXBC & FVBC CYLINDERS HAVE STAINLESS STEEL SS304 RODS

Part number Bore Rod Stroke A B C D E F G H I J K Offer Price
FXBC50X25 50 20 25 143 64 M16x1.5 1/4 32 46.5 M8 37 46.5 32 46.5 sold
FXBC50X50 50 20 50 143 64 M16x1.5 1/4 32 46.5 M8 37 46.5 32 46.5 sold
FXBC50X80 50 20 80 143 64 M16x1.5 1/4 32 46.5 M8 37 46.5 32 46.5 sold
FXBC50X100 50 20 100 143 64 M16x1.5 1/4 32 46.5 M8 37 46.5 32 46.5 £69.00
FXBC50X125 50 20 125 143 64 M16x1.5 1/4 32 46.5 M8 37 46.5 32 46.5 sold
FXBC50X160 50 20 160 143 64 M16x1.5 1/4 32 46.5 M8 37 46.5 32 46.5 sold
FXBC50X200 50 20 200 143 64 M16x1.5 1/4 32 46.5 M8 37 46.5 32 46.5 £79.00
FXBC50X250 50 20 250 143 64 M16x1.5 1/4 32 46.5 M8 37 46.5 32 46.5 sold
FXBC50X300 50 20 300 143 64 M16x1.5 1/4 32 46.5 M8 37 46.5 32 46.5 £89.00
FXBC50X400 50 20 400 143 64 M16x1.5 1/4 32 46.5 M8 37 46.5 32 46.5 £104.00
FXBC50X500 50 20 500 143 64 M16x1.5 1/4 32 46.5 M8 37 46.5 32 46.5 £119.00

Mountings available


Name A B C D E F G H I J Price
CA Mount 27  12 12.2 17 24 65 46 4x M8 screws N/A N/A £
CB Mount 27 16 12 12 67 59 65 59 46 32 £
Y Clevis 39.3 33 32 16 83 64 32 16 M16x1.5 N/A £
Spherical Bearing 21 42 16 22 28 64 85 M16x1.5 N/A N/A £
